Event Lighting 37x 20W RGBW Wash Zoom Moving Head with Pixel Control
M37W20RGBW
New
The M37W20RGBW is a powerful wash moving head, utilising 37x 20W RGBW 4-in-1 LEDs with a beam angle that varies from 6~60° as well as pixel control to generate unique effects.
Photometrics
- Light Source: 37x Osram® 20W RGBW LED
- Beam Angle: 6°~60°
- Output: 8,500 lumen, 40,560 lux RGBW full on @ 3 m at 6°, 6,760 lux RGBW full on @ 3 m at 60°
- PWM: 1,200 Hz
- LED Lifespan: 60,000 hours
Effects
- Dimming: 0~100%
- Pixel Control: Yes
- Strobe: 0.5~26 Hz
- Zoom: Motorised, 6 - 60°
Movement 8 / 16 bit Auto Reposition
- Pan: 630° (2.2 sec) or 540° (2.0 sec)
- Tilt: 265° (0.85 sec)
Power
- Input Voltage: 100~240 V AC, 50/60 Hz, 520 W
- Connection: Neutrik® PowerCON in/out
Control
- Operation Modes: DMX, auto, sound active, master/slave
- Control Protocol: DMX512, RDM, Art-Net (optional: W-DMX™)
- DMX Channels: 19 / 41 / 170 / 18 / 20
- Control Interface: 5-pin XLR, Ethernet
- Display: 2.4″ colour LCD control panel with battery power.
- Software Upgrade via DMX: Yes
Housing
- Materials: ABS and steel, matte black finish
- Cooling: Multi-sensor thermostat controlled variable speed fan
- IP rating: IP20
- Net Weight: 17 kg
- Rigging: 2x omega brackets with 1/4-turn quick locks
MISC
- Road case: MCASE2W37
