MIDAS M32 Live Digital Mixing Console
M32LIVE
New
The Midas M32 is a Live Digital Mixing Console. It offers 40 Input Channels, 32 Midas Microphone Preamplifiers and 25 Mix Buses.
MIDAS M32 Live Digital Mixing Console
The Midas M32 is a Live Digital Mixing Console. It offers 40 Input Channels, 32 Midas Microphone Preamplifiers and 25 Mix Buses.
Designing A Future Classic
Midas’ goal for M32 was to combine the best of classic British console designs with advanced modern technology. This was in order to completely redefine what a medium-format live console can offer.
What’s more, Midas began the industrial design process by drawing inspiration from a somewhat unexpected source – the luxury and high-performance car industry.
The Landmark in Console History
A close look at M32 reveals that the styling is completely new in every sense of the word. Rajesh Kutty’s automotive-inspired design elements mesh perfectly with a recognisable MIDAS signature, setting the M32 apart from any other console. Its beautifully streamlined and elegant form factor completely revolutionises the experience of live mixing.
The MIDAS M32 construction is equally impressive, and is designed to offer you years of reliable performance while withstanding the demanding environment of live performance venues. M32 employs a predominantly space-frame construction, with parts of the sub-frame consisting of durable and lightweight carbon fibre and aluminium.
Furthermore, the M32 is an innovative, evolved design that brings together modern construction principles and high-tech materials into a styling destined to go down as a landmark in console history.
Industry-Leading 192 kHz Precision with MIDAS M32
- Advanced digital technology
- Future-proof floating point audio engine
- Extremely low-latency design and industry-leading 192 kHz ADC and DAC converters
Furthermore, M32 features ultra-sleek styling, offering you a truly luxurious mixing experience. High-end construction materials include carbon fibre provide unparalleled durability and strength, plus substantially lower weight than comparable consoles.
The M32 utilises award-winning Midas PRO Series microphone preamplifiers and the custom-designed Midas PRO motorised faders that are rated for 1 million life cycles-three times more than other leading consoles.
Overall, the Midas M32 is a future-forward console that completely raises the bar for live mixing.
FEATURES:
- Your “Mind-to-Sound” Interface
- Channel Strip
- 7″ Main Display
- Sends On Fader
- DCA Groups
- View Function
- Assign Section
- “Acoustic Integration” – the Live Sound Revolution
- 100-Band RTA for all Channel/Bus EQs
- 16 Breathtaking FX “Plug-Ins” Based on True Physical Modeling
- Gain Splitting and remote Control for FOH and Monitoring
- More Routing and Processing Flexibility
- Mighty New Tools for Scene and Show Management
- The MIDAS PRO FADER – rated for 1 Million Life Cycles
- LED Scribble Strips
- Virtual Effects Rack
SPECS:
Input/Output Characteristics
Frequency Response @ 48 kHz Sample Rate: 0 dB to -1 dB 20 Hz – 20 kHz
Dynamic Range, Analogue In to Analogue Out: 106 dB 22 Hz – 22 kHz unweighted
A/D Dynamic Range, Preamplifier and Converter (Typical): 109 dB 22 Hz – 22 kHz unweighted
D/A Dynamic Range, Converter and Output (Typical): 109 dB 22 Hz – 22 kHz unweighted
Crosstalk Rejection @ 1 kHz, Adjacent Channels: 100 dB
Output level, XLR Connectors (Nominal / Maximum): +4 dBu / +21 dBu
Output Impedance, XLR Connectors (Unbalanced / Balanced): 50 Ω / 50 Ω
Input impedance, TRS Connectors (Unbalanced / Balanced): 20 kΩ / 40 kΩ
Non-Clip Maximum Input Level, TRS Connectors: +21 dBu
Output Level, TRS (Nominal / Maximum): +4 dBu / +21 dBu
Output Impedance, TRS (Unbalanced / Balanced): 50 Ω / 50 Ω
Phones Output Impedance / Maximum output Level: 40 Ω / +21 dBu (Stereo)
Residual Noise Level, Out 1-16 XLR Connectors, Unity Gain: -85 dBu 22 Hz-22 kHz unweighted
Residual Noise Level, Out 1-16 XLR Connectors, Muted: -88 dBu 22 Hz-22 kHz unweighted
Residual Noise Level, TRS and Monitor out XLR Connectors: -83 dBu 22 Hz-22 kHz unweighted
Display
Main Screen: 7” TFT LCD, 800 x 480 Resolution, 262k Colours
Channel LCD Screen: 128 x 64 LCD with RGB Colour Backlight
Main Meter: 24 Segment (-57 dB to Clip)
Power
Switch-Mode Power Supply: Auto-Ranging 100-240 VAC (50/60 Hz) ± 10%
Power Consumption: 120 W
Physical
Standard Operating Temperature Range: 5°C – 40°C (41°F – 104°F)
Dimensions: 891 x 612 x 256 mm (35.1 x 23.9 x 10.1”)
Weight: 24.5 kg (53.9 lbs)
